Machineries we manufacture



PAVER BLOCK MACHINE

Specifications & Features :
Maximum High Pressure Tonnage 80
Manufacturing Capacity
450mm x 450mm MOSAIC TILES
450mm x 300mm x 150mm KERB Stone
Trolley System-Mould moves/operates through Trolley
Safe working conditions with electrical and mechanical interlock systems
Power Required: 5HP and 3 HP
Each Paver Machine can give Production of 1400 to 1800 Nos. Pavers in 1 shift
Oil tank Capacity: 180 Liters

VIBRO WITH HIGH PRESSURE PAVER BLOCK MACHINE


Maximum High Pressure Tonnage 80
Oil cooling System Facilitate to cool down oil even Press is working.
Auto Stop.
Safe working conditions with electrical and mechanical interlock systems.
Superior Vibration and Pressing systems for maximum compaction and strength.
The Pressing operation is time controlled with single switch operation for both pressing and return strokes ensuring uniform pressure on all sides of paver block.
Power Required : 10HP & 3 HP
Each Paver Machine can give production of 1400 to 180 nos. Paver Block in 1 shift.
Manufacturing capacity : Paver Block & 450mm x 300mm x 150mm Kerb Stone oil tank capacity :200 liters.


DOUBLE DISC FLOOR POLISHING MACHINE



Specification :
Machine : Robust in design but portable.
Steel Gears and Pinions : Dully tempered.
Motor Power : Either. 2 HP or 1.5KW-200/1/50.Cycles, 1400/1500 RPM OR 3HP or 1.5KW-400/3/50
Ball Bearing : 11 Numbers.
Revolution of Disc : 150 approx per minute
Triangular Abrasive : 6 Numbers of each grade.
Grade of Abrasive Stone : Coarse, medium and Fine.
Output : 200 sq. Ft. or 18.58 sq. Mt. approx.

BALL PRESS


Technical Specilication :
Body : made of high grade cast iron with chemicals increase its rigidity and long lasting.
Arms : Made of steel durable Rall 5-6 Long Approx.
Bills : Made of cast Iron 10" Round-2 Nos. approx.
Woriking Table : 18" x17" or 457.2mm x 431.8 mm approx. Hand operated.
Height between the Pressing Stock : Surace 9' or 228.6mm approx.
Output : 1600 Nos Tiles approx of 200 x 200mm. sq. by 4 workmen or 1000 nos Tiles approx of 250 x 250mm. sq. by workmen, or 600 nos Tiles approx of 200 x 200mm. sq. by 4 workmen.
Working capacity : Cement Tiles and other necessary work.

BALL MILL


Technical Spectfication :
Drum Size : 4'-0" Long 2'-6" Diameter M.S. Shet think of Body 6 MM and Sice wall thickness 12MM Dholky Type.
Stand : Cast Iron Best Quality Stand.
Gear : Steet gear with C. I. Gear.
Ball : 2" size 10 nos. & 3.5" size 10nos. C. I. Balls.
Motor Power : 5 HP or 3.7 KW A>C> 1400 RPM 440 Volts 3 Phase 50 Cycles Motor combined 'V' belt system.
Working : Dry Colour Oxide Mixing Machine.
Output : Colour Oxice 8 hour approx. compound mixing 1 Hours approx.

SUPER LEVELLING OR GRINDING MACHINE


Specification :
Machine : Robust in design but portable.
Steel Gears and Pinions : Dully tempered.
Motor Power : Either. 2 HP or 1.5KW-200/1/50.Cycles, 1400/1500 RPM OR 3HP or 1.5KW-400/3/50
Ball Bearing : 11 Numbers.
Revolution of Disc : 150 approx per minute
Triangular Abrasive : 6 Numbers of each grade.
Grade of Abrasive Stone : Coarse, medium and Fine.
Output : 200 sq. Ft. or 18.58 sq. Mt. approx.

PAN MIXERS


Technical Specilication :
Are made up of special fitted with antifrictiin bearings and 'O' rings to last long.
Loading of raw materials : Manual or by skip.
Unloading of Mix : Bottom discharge through sliding door operated by rack & pinion manually or motorized.
Optional :
1. Raw materials loading skip.
2. Discharge door motorized opening and     automatic closing.
3. Electronic weighing load cells for weigh     batching of raw materials.
4. water dosing pump.

TABLE VIBRATOR


Technical Specilication :
Production Capacity : 2000sq.ft. / 8 hours shift
Power(3 h.p. motor / table * 2 tables) : 6 H.P
Vibrating Table Size : 850 * 6000 mm
Maximum size of the tile : 600 * 600 mm
Maximum height of the tile : 100 (recommended)
Movement of rubber mould in vibrator table : Due to vibration with manual intervention
Dimension l*b*h : 7860 * 925 *1050 mm
Total weight : 600 kg * 2 (approx)

FLY-ASH BRICKS MAKING MACHINE SPECIFICATION


1.Electric Motor:15hp.(Crompton/ABB Motor).
2.Bricks & Block size:(225x110x75)                               (250x125x75)m/m.
3.Pressure Capacity:150 Ton Approx.
4.Production Capacity:1,200 To1,500 Nos.
                                Bricks in One hour.
5.Bricks per Stroke:10/12 Bricks.
6.Pallet Feeding:Automatic.
